Pellet Boilers
Axinar CALOS CL8–32 All-in-One Pellet Unit 8–32kW with Automatic Cleaning
SKU: PRO-SYS-000008
The Axinar CALOS CL8–32 is a ready-to-use all-in-one pellet unit, specially designed for residential heating applications that require high output, compact dimensions, and minimal maintenance. It integrates all necessary hydraulic components for quick installation and effortless operation.
See the full description
3.65100 €
In stock
VAT included
Delivery time: confirmed after the order
Shipping by arrangementThey depend on weight, volume and area. We inform you before the order is finalised.
Delivery is made to the entrance of the building. For an upper floor or indoors, prior arrangement is required.
- Made in Greece
- 10-year warranty
- Delivery across Greece
And if it breaks?
Covered by a manufacturer warranty. Service is handled by our own technical department, with no middlemen.
And if I change my mind?
You have the right of withdrawal within 14 days from receipt, with the product in its original condition. Return costs are borne by the buyer.
I want an invoice or a quote for a larger quantity?
Click Request a Quote and we reply with a written quote, an invoice and a delivery time for the quantity you need.
The CALOS unit delivers between 8 and 32kW, offering flexibility for different heating needs, especially in spaces with limited available room.
It is pre-equipped with:
• Circulator pump
• Expansion vessel
• Safety valve
• Automatic air vent
• Automatic filling valve with pressure gauge
Key Features:
• All-in-one pellet system – plug & heat
• Automatic self-cleaning for easy maintenance
• Compact design for easy transport and installation
• Power output: 8–32 kW / 6,900–27,500 Kcal
• Ash drawer capacity: 15 L
• Dimensions (HxWxD): 1900 x 750 x 320 mm
In-house manufacturing
How This Product Was Made
All processes happen at our facilities in Thessaloniki, from the first sheet metal to packaging. No outsourcing.
01 — DESIGN
R&D / Mechanical Design
3D modeling, DFM optimization.
→02 — CUTTING
Laser Cutting
Fiber laser 20kW on steel up to 40mm for body sheets.
→03 — FORMING
Press Brake
7-axis Delem CNC for precise shell and heat-exchanger bends.
→04 — PRECISION
CNC Milling
Haas VF2 for precision holes, mechanism flanges and threading.
→05 — WELDING
MIG/TIG Welding
Fronius pulse welders for water-vessel sealing and long-term durability.
→06 — WELDING
Laser Welding
3kW laser for clean, narrow seams on visible surfaces.
→07 — FINISHING
Deburring
Burr removal and surface preparation before powder coating.
→08 — COATING
Powder Coating
Qualicoat powder coating, 15+ years outdoor durability.
→| Power (kW) | 8 - 32 |
|---|---|
| Power (kcal) | 6.900 - 27.500 |
| Dimensions | 75 × 32 × 190 cm |
